Customer Requirement

• 3-axis for the system controllable axis number (2-axis for the grinding belt machine);
• To carry out the procedure editing function of grinding machine;
• To achieve DXF drawing leading the CNC processing program production;
• To carry out the function of automatic grinding wheel trimming and the section compensation of the path of grinding tool.

• Using 990MC control to perform the function development based on the version of V1.5MDJ;
• Adding the DXF graph edited from computer to the CNC system; the system is automatically produced the function of grinding tool program;
• Adding the corresponding axis of each block on the path of grinding tool to perform the section compensation;
• Adding the multi-procedure editing function of grinding tool can be edited the on-line procedure machining.

• DXF diagraph leads into the CNC system to automatically produce the grinding tool program, and save the time that the system panel is edited by manual;
• Procedure edit and section compensation can be shortened the production efficiency time of workpiece and improve its productiveness;
• The dedicated interface is simple and convenient of which the customer needs only to fill the relevant variables and then the machining program can be automatically produced;
• The grinding processing of Multi-grinding tools can be carried out and the diversification of machining product.
